Affordable Detachable Container House For Mining Area Dormitory

affordable detachable container dormitory
detachable container house for dormitory
detachable container mining area dormitory
low cost container mining area dormitory

Affordable Detachable Container House For Mining Area Dormitory

1. Container dormitories can be built quickly and are easier to install than traditional buildings.
2. The construction cost of the container dormitory is low, which is more cost-effective than traditional buildings.
3. The container dormitory can be rapidly expanded according to the needs without restarting the construction.
4. The container dormitory can be quickly disassembled as needed and can be reused.

  • Item No :

    DC08

  • Order(MOQ) :

    5

  • Payment :

    Telegraphic Transfer

  • Product Origin :

    China

  • Color :

    Customized

  • Shipping Port :

    Guangzhou/Shenzhen/Foshan

  • Lead Time :

    3-15
Inquiry now

Affordable Detachable Container House For Mining Area Dormitory

Detachable container dormitory is the perfect accommodation solution for mines and workers, offering both comfort and affordability.



Detachable Container House

Steel: Q235B Stainless Steel, 2.3mm

Q235B has certain elongation, strength, good toughness and castability, easy to punch and weld, and is widely used in the

manufacture of general mechanical parts. It is mainly used for welded structural parts with high quality requirements in

construction and bridge engineering.

PRODUCT SPECIFICATION



Quotation list of Detachable container house
No. Component Specification Unit Quantity Remarks
1 Column 2480*2.3 Strip 4 High of Beam:195MM
2 Bottom Beam 5630*2.3 Strip 2 Sink:65MM
3 Bottom Beam 2680*2.3 Strip 2 Thickness:2.3MM Hot-dip Galvanized Sheet Profile
4 Top Beam 5630*2.3 Strip 2 /
5 Top Beam 2680*2.3 Strip 2 /
6 Corner Piece 195*165*4 Piece 8 /
7 Top Platen Slot 5730*1.2 Strip 2 Galvanized
8 Top Platen Slot 2790*1.2 Strip 2
9 Corner Fitting 120*1.2*2530 Strip 1
10 Bottom Beam SquareTube 100*50*2980*1.3 Strip 9 Galvanized
11 Top Beam SquareTube 50*50*2800*1.8 Strip 2 Galvanized, with Card Slots On Both Sides
12 Top Beam SquareTube 80*40*1880*1.5 Strip 3 Galvanized
13 Top Beam Square Tube 60*40**1880*1.5 Strip 6
14 Main Frame Bolt ST100*30 Piece 64 Carriage Bolt
15 Bottom Beam Bolt ST100*80 Piece 18
16 Floor 2800*1146*18 Sheet 5 MGO Fireproof Board
17 Structural Adhesive   Piece 5 /
18 Ceiling Board 2788*200*0.3 Piece 29 /
19 Roof Tile 2920*950*0.5 Piece 6 /
20 Roll Felt 20M Roll 1 /
21 Hardware   Carton 1 /
22 Butyl Rubber Strip   M 12 /
23 Corner Fitting 38 Strip 2 /
24 Door 925*2050 Piece 1 /
25 Window 925*1200 Piece 2 /
26 Board Material 2560*950*50 Piece 15 0.276Glass Wool Board
27 Board Material 1380*950*50 Piece 2 0.276Glass Wool Board
28 Board Material 460*950*50 Piece 1 0.276Glass Wool Board





Detachable Container House

Name

Material

Specification

Structure Frame
Galvanized square tube+
Spray paint

Corner Column

2480*160*160, T2.3mm

Bottom Main Beam

5630*160*160, T2.3mm

Bottom Short Beam

2680*160*160, T2.3mm

Bottom Purlin

2990*80*80, T1.2mm

2990*40*80, T1.1mm

Top Main Beam

5630*160*160, T2.3mm

Top Short Beam

2680*160*160, T2.3mm

Top Purlin

2800*50*50, T1.5mm

1880*40*80, T1.1mm

1880*40*60, T1.0mm

Corner Fitting

160*160*4.5mm

Water Plate Channel

5740*130*2.0mm
2800*130*2.0m





product installation

Office：Removable, Expandable, Reusable, 20 Years Life

Type: Flat Pack Prefab Container Office

Application: Temporary offices in construction sites, office built in workshops, low-cost outdoor offices.

Advantages: Short installation time, 1-15 days, depending on the project, a single container office only needs one day to complete the installation.



Supporting Facilities

Wall + Floor：Choose high-quality fire and moisture-proof materials

Wall panel: rock wool/glass wool color steel plate.Fire rating: Class A; Moisture-proof rating: Class A

Floor: PVC+glass magnesium board or PVC+cement.It has very good hardness, and it is also a fireproof and moisture-proof material

LAYOUT:

1. General layout: the empty box with two windows, and one door

2. Free layout: change according to customer requirements (design drawings are made according to the type and quantity of personnel)

SUPPORTING FACILITIES
